คุณสมบัติHARDWARE FEATURESStandards and Protocols• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q • TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, SNMPInterface• 2 Gigabit SFP WAN/LAN ports • 1 Gigabit WAN port • 1 Gigabit LAN/WAN port • 8 Gigabit LAN portsNetwork Media• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)Fan QuantityFanlessButtonReset ButtonPower Supply53.5VDC/2.43A AdapterPoE Budget8 ports PoE output, 110 W PoE BudgetFlash8Mb Nor 4 GB EMMCDRAM1 GB DDR3LEDPWR, SYS, CLOUD, PoE Max, SFP 1, SFP 2, WAN (Speed, Link/Act), LAN (Speed, Link/Act)Dimensions ( W x D x H )8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)Protection4 kV surge protectionEnclosureSteelMountingDesktop/Wall-mountMax Power Consumption• 133.2W with PoE Max • 13.88W without PoEPERFORMANCEConcurrent Session24,980New Sessions /Second1,900NAT (Static IP)935.5 Mbps / 942.1 MbpsNAT(DHCP)940.2 Mbps / 941.7 MbpsNAT(PPPoE)913.1 Mbps / 935.2 MbpsNAT (L2TP)545.0 Mbps / 912.7 MbpsNAT (PPTP)523.0 Mbps / 912.8 MbpsIPsec VPN Throughput (AES256)168.5 MbpsIPsec VPN ThroughputAES256: 168.5 MbpsOpenVPN34 MbpsL2TP VPN Throughput• Unencrypted: 845.3 Mbps • Encrypted: 333.2 MbpsPPTP VPN Throughput• Unencrypted: 1012.6 Mbps • Encrypted: 401.4 Mbps66 Byte Packet forwarding rate154,069 pps / 156,977 pps1,518 Byte Packet forwarding rate81,193 pps / 81,193 ppsBASIC FUNCTIONSWAN Connection Type• Static IP • Dynamic IP • PPPoE • PPTP • L2TPMAC CloneModify WAN MAC AddressDHCP• DHCP Server • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCPIPv6supportVLAN802.1Q VLANIPTVIGMP v2/v3 ProxyADVANCED FUNCTIONSACLIP/Port/Protocol/Domain Name FilteringAdvanced Routing• Static Routing • Policy RoutingBandwidth ControlIP/Port-based Bandwidth ControlLoad Balance• Intelligent Load Balance • Application Optimized Routing • Link Backup • Online DetectionNAT• Multi-Net NAT • Virtual Server • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnPSession LimitIP-based Session LimitVPNSSL VPN–IPsec VPN• 20 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • AES128, AES192, AES256 Encryption Algorithm • IKE v1/v2 • SHA1, SHA2 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS)PPTP VPN• PPTP VPN Server • PPTP VPN Client (10) • 16 Tunnels • PPTP with MPPE EncryptionL2TP VPN• L2TP VPN Server • L2TP VPN Client (10) • 16 Tunnels • L2TP over IPSecOpenVPN• OpenVPN Server • OpenVPN Client (10)§ • 16 OpenVPN TunnelsSECURITYFilteringURL FilteringARP Inspection–Attack Defense• TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WANAccess ControlSource/Destination IP Based Access ControlAUTHENTICATIONWeb Authentication• No Authentication • Simple Password • Hotspot (Local User / Voucher / SMS / Radius) • External Radius Sever • External Portal SeverMANAGEMENTOmada AppYesCentralized Management• Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller • Omada Cloud-Based ControllerCloud AccessYesServiceDynamic DNS (Dyndns, No-IP)Maintenance• Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3 • Syslog SupportZero-Touch ProvisioningYes. Requiring the use of Omada Cloud-Based Controller.Management Features• Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration • Management up to 1 Router, 2 Switches and 10 EAPsOTHERSCertificationCE, FCC, RoHSPackage Contents• ER7212PC • Power Adapter • Power Cord • Quick Installation GuideSystem Requirements• Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10 • MAC OS, NetWare, UNIX or LinuxEnvironment• Operating Temperature: 0 °C to 45 °C (32 °F to 113 °F) • Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) • Operating Humidity: 10% to 90% non-condensing • Storage Humidity: 5% to 90% non-condensing รหัสสินค้า: TPL-ER7212PC หมวดหมู่: Router TP-Link
