คุณสมบัติHARDWARE FEATURESStandards and Protocols• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q • TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMPInterface• 1 Gigabit SFP WAN/LAN Port • 1 Gigabit WAN Port • 4 Gigabit LAN/WAN Ports • 1 USB 3.0 Port (supports USB LTE dongle and USB storage)Network Media• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)Fan QuantityFanlessButtonReset ButtonPower Supply12V DC/ 1A Power AdapterPoE Budget–Flash128 MB NANDDRAM512 MB DDR4LEDPWR, SYS, SFP, USB, WAN(1000M Link/Act, 100/10M Link/Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act)Dimensions ( W x D x H )8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)Protection4 kV surge protectionEnclosureSteelMountingDesktop/ Wall-MountingMax Power Consumption• 7.5 W (with USB 3.0 connected) • 4.5 W (without USB 3.0 connected)PERFORMANCEConcurrent Session150,000New Sessions /Second5,300NAT (Static IP)945.3 Mbps / 940.5 MbpsNAT(DHCP)939.6 Mbps / 940.9 MbpsNAT(PPPoE)943.6 Mbps / 940.9 MbpsNAT (L2TP)880.1 Mbps / 859.0 MbpsNAT (PPTP)855.0 Mbps / 907.2 Mbps64 Byte Packet Forwarding Rate–IPsec VPN Throughput• ESP-SHA1-AES256: 617.1 Mbps • ESP-SHA256-AES256: 592.8 Mbps • ESP-SHA384-AES256: 592.4 Mbps • ESP-SHA512-AES256: 604.5 MbpsOpenVPN139.1 MbpsL2TP VPN Throughput• Unencrypted: 977.4 Mbps • Encrypted: 334.6 MbpsPPTP VPN Throughput• Unencrypted: 1064.1 Mbps • Encrypted: 206.8 MbpsSSL VPN Throughput131.6 Mbps66 Byte Packet forwarding rate1,453,489 pps / 1,453,488 pps1,518 Byte Packet forwarding rate81,279 pps / 81,275 ppsBASIC FUNCTIONSWAN Connection Type• Static IP • Dynamic IP • PPPoE(supports MRU Configuration) • PPTP • L2TPMAC CloneModify WAN/LAN MAC Address†DHCP• DHCP Server • DHCPv6 PD Server (only in Standalone Mode) • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCPIPv6StaticIP/SLAAC/DHCPv6/PPPoE/6to4Tunnel/PassThrough/Non-Address modeVLAN802.1Q VLANIPTVIGMP v2/v3 Proxy, Custom Mode, Bridge ModeADVANCED FUNCTIONSACLIP/Port/Protocol/Domain Name FilteringAdvanced Routing• Static Routing • Policy Routing • RIP§ • OSPF§Bandwidth ControlIP-based Bandwidth ControlLoad Balance• Intelligent Load Balance • Application Optimized Routing • Link Backup (Timing, Failover) • Online DetectionNAT• One-to-One NAT • Multi-Net NAT • Virtual Server • Port Triggering§ • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnPSession LimitIP-based Session LimitVPNSSL VPN50 TunnelsIPsec VPN• 100 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, AES128, AES192, AES256 Encryption Algorithm • IPsec Failover • IKE v1/v2 • MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS)PPTP VPN• PPTP VPN Server • PPTP VPN Client (10)‡ • 50 Tunnels • PPTP with MPPE EncryptionL2TP VPN• L2TP VPN Server • L2TP VPN Client (10)‡ • 50 Tunnels • L2TP over IPSecOpenVPN• OpenVPN Server • OpenVPN Client (5)‡ • 55 OpenVPN Tunnels • “Certificate Account” Mode • Full ModeSECURITYFiltering• WEB Group Filtering§ • URL Filtering • Web Security§ARP Inspection• Sending GARP Packets§ • ARP Scanning§ • IP-MAC BindingAttack Defense• TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WANAccess ControlSource/Destination IP Based Access ControlAUTHENTICATIONWeb Authentication• No Authentication • Simple Password* • Hotspot(Local User /Voucher*/ SMS*/Radius*) • External Radius Sever • External Portal Sever* • LDAP§MANAGEMENTOmada AppYes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.Centralized Management• Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software ControllerCloud AccessYes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.ServiceDynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)Maintenance• Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3 • Diagnostics (Ping & Traceroute)§ • NTP Synchronize§ • Port Mirroring • CLI (only in Standalone Mode) • Syslog SupportZero-Touch ProvisioningYes. Requiring the use of Omada Cloud-Based Controller.Management Features• Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal ConfigurationOTHERSCertificationCE, FCC, RoHSPackage Contents• ER7206(TL-ER7206) • Power Cord • Quick Installation GuideSystem RequirementsMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10 MAC OS, NetWare, UNIX or LinuxEnvironment• Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) • Operating Humidity: 10% to 90% non-condensing • Storage Humidity: 5% to 90% non-condensing รหัสสินค้า: TPL-ER7206 หมวดหมู่: Router TP-Link
