SECURITYAccess ControlSource/Destination IP Based Access ControlFiltering• WEB Group Filtering§ • URL Filtering • Web Security§ARP Inspection• Sending GARP Packets§ • ARP Scanning§ • IP-MAC Binding§Attack Defense• TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WANHARDWARE FEATURESStandards and Protocols• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q， IEEE802.3bz • TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP, WireGuard VPNInterface• 1× 2.5G RJ45 WAN Port • 1× 2.5G RJ45 WAN/LAN Port • 1× Gigabit SFP WAN/LAN Port • 4× Gigabit RJ45 WAN/LAN Ports • 1× USB 2.0 Port (Supports USB storage, and LTE backup with LTE dongle)Network Media• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) • 2500BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)Fan QuantityFanlessButtonReset ButtonPower Supply12V/1.5A AdapterPoE Budget–Flash128MB NANDDRAM1 GB DDR4LEDPWR, SYS, SFP, USB, WAN (Speed, Link/Act), LAN (Speed, Link/Act)Dimensions ( W x D x H )8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)Protection4 kV surge protectionEnclosureSteelMountingRackmout, Desktop, or Wall MountMax Power Consumption14.2 W (with USB2.0 connected) 7.1 W (without USB2.0 connected)PERFORMANCEIPS ThroughputTCP: 208 Mbps; UDP: 161 MbpsDPI ThroughputTCP: 1823 Mbps; UDP: 1272 MbpsWireGuard VPN Throughput343MbpsConcurrent Session500,000New Sessions /Second6,000NAT (Static IP)2365.17 Mbps / 2364.45 MbpsNAT(DHCP)2364.45 Mbps / 2366.04 MbpsNAT(PPPoE)2347.14 Mbps / 2348.29 MbpsNAT (L2TP)1308.86 Mbps / 974.10 MbpsNAT (PPTP)1236.27 Mbps / 1280.99 MbpsIPsec VPN Throughput• ESP-SHA1-AES256: 673.3 Mbps • ESP-SHA256-AES256: 650.2 Mbps • ESP-SHA384-AES256: 629.3 Mbps • ESP-SHA512-AES256: 633.8 MbpsL2TP VPN Throughput• Unencrypted: 1243.7 Mbps • Encrypted: 561.0 MbpsSSL VPN Throughput132.24 Mbps66 Byte Packet forwarding rate1832.69 Mbps / 1741.84 Mbps1,518 Byte Packet forwarding rate2461.18 Mbps / 2457.32 MbpsBASIC FUNCTIONSWAN Connection Type• IPv4_Static IP • IPv4_Dynamic IP • IPv4_PPPOE • IPv4_L2TP • IPv4_PPTP • IPv6_PPP • IPv6_DHCPv6 • IPv6_Static IP • IPv6_6in4 • IPv6_Pass-Through • Mobile Broadband: 4G/3G modem for backup via USB portMAC CloneModify WAN/LAN MAC Address†DHCP• DHCP Server • DHCPv6 PD Server (only in Standalone Mode) • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces* • Multi-Net DHCP*IPv6StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address modeVLAN802.1Q VLANIPTVIGMP v2/v3 Proxy, Custom Mode, Bridge ModeADVANCED FUNCTIONSAdvanced Routing• Static Routing • Policy Routing • RIP (only in Standalone Mode) • OSPF (only in Standalone Mode)Bandwidth Control• IP/Port-based Bandwidth Control • Guarantee & Limited BandwidthLoad Balance• Intelligent Load Balance • Application Optimized Routing • Link Backup (Timing§, Failover) • Online DetectionNAT• One-to-One NAT§ • Multi-Net NAT • Port Forwarding • Port Triggering§ • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnPSession LimitIP-based Session LimitVPNIPsec VPN• 100 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, SHA1, AES128, AES192, AES256 Encryption Algorithm • IKEv1/v2 • MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS)PPTP VPN• PPTP VPN Server • PPTP VPN Clients (12) • 60 Tunnels (Shared with L2TP) • PPTP with MPPE EncryptionL2TP VPN• L2TP VPN Server • L2TP VPN Clients (12) • 60 Tunnels (Shared with PPTP) • L2TP over IPSecOpenVPN• OpenVPN Server • OpenVPN Clients (6) • 66 OpenVPN Tunnels*WireGuard VPN• 20 TunnelsAUTHENTICATIONWeb Authentication• No Authentication • Simple Password* • Hotspot (Local User/Voucher*/SMS*/Radius*) • External Radius Server • External Portal Server* • LDAPMANAGEMENTOmada AppYes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.Centralized Management• Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software ControllerCloud AccessYes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.ServiceDynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)Maintenance• Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3* • Diagnostics (Ping & Traceroute)§ • NTP Synchronize§ • Port Mirroring • CLI (only in Standalone Mode) • Syslog SupportZero-Touch ProvisioningYes. Requires the use of Omada Cloud-Based Controller.Management Features• Automatic Device Discovery* • Batch Configuration* • Batch Firmware Upgrading* • Intelligent Network Monitoring* • Abnormal Event Warnings* • Unified Configuration* • Reboot Schedule*OTHERSCertificationCE, FCC, RoHSPackage Contents• ER707-M2 • Power Adapter • Quick Installation Guide • Rackmount KitSystem RequirementsMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or LinuxEnvironment• Operating Temperature: 0–40 ℃ (32–104 ℉); • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% non-condensing รหัสสินค้า: ER707-M2 หมวดหมู่: Router TP-Link
