คุณสมบัติ4GNetwork TypeLTE Band of EU: • 4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32 (2100/1800/850/2600/900/800/700/1450 MHz) • 4G LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz) • 3G DC-HSDPA/HSPA /HSDPA/HSUPA/WCDMA: B1/B3/B5/B8 (2100/1800/850/900 MHz)Carrier Aggregation: B1 B1/B3/B5/B7/B8/B20/B28/B38/B40/B41 B3 B3/B5/B7/B8/B20/B28/B38/B40/B41 B5 B5/B7/B38/B40/B41 B7 B7/B8/B20/B28/B32 B8 B32/B38/B40/B41 B20 B32/B38/B40 B28 B32/B38/B40/B41 B38 B38 B40 B40 B41 B41SIM Type1× Nano SIM CardFrequency• Downlink: 300 Mbps; • Uplink: 50 MbpsSECURITYAccess ControlSource/Destination IP Based Access ControlFiltering• Web Group Filtering† • URL Filtering • Web Security†ARP Inspection• Sending GARP Packets • ARP Scanning† • IP-MAC BindingAttack Defense• TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WANHARDWARE FEATURESInterface• 1 Gigabit SFP WAN/LAN Port • 1 Gigabit WAN Port • 4 Gigabit LAN/WAN PortsNetwork Media• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)ButtonReset ButtonPower Supply12VDC / 2A Power AdapterWi-Fi Frequency & Signal Rate• 2.4 GHz: 574 Mbps • 5 GHz: 2402 Mbps (HE160)Flash128 MB NANDDRAM512 MB DDR4LEDSYS, WLAN, SFP, LTE Signal, WAN (1000M Link/Act, 100/10M Link/Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act)Dimensions ( W x D x H )8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) (Antenna dimensions are not included)Antenna• Wi-Fi: Three 5GHz 5.5dBi & 2.4GHz 4.5dBi dual-band detachable antennas • LTE: Two 4.0dBi omnidirectional detachable antennasMountingDesktop/Wall-MountingMax Power ConsumptionEU: 17.3WPERFORMANCEGRE• Unencrypted: 545.3Mbps • Encrypted: 282.6MbpsWireGuard VPN387.7MbpsConcurrent Session150,000New Sessions /Second5,100NAT (Static IP)947.1Mbps / 940.1MbpsNAT(DHCP)949.2Mbps / 941.1MbpsNAT(PPPoE)942.6Mbps / 941.1MbpsNAT (L2TP)875.4Mbps / 892.0MbpsNAT (PPTP)881.2Mbps / 895.8MbpsIPsec VPN Throughput• ESP-SHA1-AES256: 652.2Mbps • ESP-SHA256-AES256: 654.4Mbps • ESP-SHA384-AES256: 646.5Mbps • ESP-SHA512-AES256: 670.5 MbpsOpenVPN115.5MbpsL2TP VPN Throughput• Unencrypted: 990.0Mbps • Encrypted: 475.0MbpsPPTP VPN Throughput• Unencrypted: 1177.9Mbps • Encrypted: 177.4MbpsSSL VPN Throughput122.5Mbps66 Byte Packet forwarding rate1,453,489 pps / 1,453,488 pps1,518 Byte Packet forwarding rate81274 pps / 91275 ppsWIRELESS FEATURESAdvanced Functions• Seamless Roaming • Mesh (with EAP that supports Mesh) • OFDMA • Beamforming • MU-MIMO • Rate Limit: Based on SSID/Client • Airtime Fairness • Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise • Multiple SSIDs: 16 in total (8 per radio)Guest NetworkSupportBASIC FUNCTIONSWAN Connection Type• Static IP • Dynamic IP • PPPoE (supports MRU Configuration) • PPTP • L2TPMAC CloneModify WAN AddressDHCP• DHCP Server • DHCPv6 PD Server (only in Standalone Mode) • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCPSMSReceive / Send SMSIPv6StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address modeVLAN802.1Q VLANIPTVIGMP v2/v3 Proxy, Custom Mode, Bridge ModeADVANCED FUNCTIONSACLIP/Port/Protocol/Domain Name FilteringAdvanced Routing• Static Routing • Policy Routing • RIP† • OSPF†Bandwidth ControlIP-Based Bandwidth ControlLoad Balance• Intelligent Load Balance • Application Optimized Routing • Link Backup(Timing, Failover) • Online DetectionNAT• One-to-One NAT • Multi-Net NAT • Virtual Server • Port Triggering† • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnPSession LimitIP-Based Session LimitVPNGREOnly in Standalone ModeSSL VPN50 TunnelsIPsec VPN• 100 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, AES128, AES192, AES256 Encryption Algorithm • IPsec Failover • IKE v1/v2 • MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS)PPTP VPN• PPTP VPN Server • PPTP VPN Client (10)△ • 50 Tunnels • PPTP with MPPE EncryptionL2TP VPN• L2TP VPN Server • L2TP VPN Client (10)△ • 50 Tunnels • L2TP over IPSecOpenVPN• OpenVPN Server • OpenVPN Client (5)△ • 55 OpenVPN Tunnels • “Certificate Account” Mode • Full ModeAUTHENTICATIONWeb Authentication• No Authentication • Simple Password§ • Hotspot (Local User / Voucher§ / SMS§ / Radius§) • External Radius Sever • External Portal Sever§ • LDAPMANAGEMENTOmada AppYes.Centralized Management• Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software ControllerCloud AccessYes.ServiceDynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)Maintenance• Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3 • Diagnostics (Ping & Traceroute)† • NTP Synchronize† • Port Mirroring • CLI (only in Standalone Mode) • Syslog SupportZero-Touch ProvisioningYes. Require the use of Omada Cloud-Based Controller.Management Features• Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal ConfigurationOTHERSCertificationCE, FCC, RoHSPackage Contents• ER706W-4G • Power Adapter • Quick Installation GuideSystem Requirements• Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11 • MAC OS, NetWare, UNIX or LinuxEnvironment• Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) • Operating Humidity: 10% to 90% non-condensing • Storage Humidity: 5% to 90% non-condensing รหัสสินค้า: TPL-ER706W-4G หมวดหมู่: Router TP-Link
