คุณสมบัติSECURITYAccess ControlSource/Destination IP Based Access ControlFiltering• WEB Group Filtering§ • URL Filtering • Web Security§ARP Inspection• Sending GARP Packets§ • ARP Scanning§ • IP-MAC Binding§Attack Defense• TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WANHARDWARE FEATURESStandards and Protocols• IEEE 802.3, 802.3u, 802.3ab, IEEE 802.3x, IEEE 802.1q • TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMPInterface• 1 Fixed Gigabit WAN Port • 2 Fixed Gigabit LAN Ports • 2 Changeable Gigabit WAN/LAN Ports • 1 USB 2.0 Port (Connecting 4G/3G Modem as WAN Backup‡)Network Media• 10BASE-T: UTP category 3, 4, 5 cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) • 100BASE-TX: UTP category 5, 5e cable (Max 100m) EIA/TIA-568 100Ω STP (Max 100m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)Fan QuantityFanlessButtonReset ButtonPower SupplyExternal 12V/1A DC AdapterPoE Budget–Flash128 MB NANDDRAM256 MB DDRLEDPWR, SYS, WAN (Link/Act), LAN (Link/Act), USBDimensions ( W x D x H )6.2 × 4.0 × 1.0 in (158 × 101 × 25mm)Protection4 kV surge protectionEnclosureSteelMountingDesktop/Wall-mountMax Power Consumption7.94 WPERFORMANCEConcurrent Session150,000New Sessions /Second2,600NAT (Static IP)• Upload: 945.77 Mbps • Download: 945.56 Mbps • Bi-Directional: 1808.29 MbpsNAT(DHCP)• Upload: 945.93 Mbps • Download: 945.43 Mbps • Bi-Directional: 1808.11 MbpsNAT(PPPoE)• Upload: 940.44Mbps • Download: 940.52 Mbps • Bi-Directional: 1804.27 MbpsNAT (L2TP)• Upload: 845.64 Mbps • Download: 802.65 Mbps • Bi-Directional: 931.96 MbpsNAT (PPTP)• Upload: 771.66 Mbps • Download: 874.81 Mbps • Bi-Directional: 999.54 Mbps64 Byte Packet Forwarding Rate• Upload/Download: 1,402,238 pps • Bi-Directional: 1,681,548 ppsIPsec VPN Throughput• ESP-MD5-AES256: 171.26 Mbps • ESP-SHA1-AES256: 224.86 Mbps • ESP-SHA2-AES256: 248.04 MbpsOpenVPN• 21.70 MbpsL2TP VPN Throughput• Unencrypted: 864.65 Mbps • Encrypted: 47.11 MbpsPPTP VPN Throughput• Unencrypted: 703.20 Mbps • Encrypted: 76.65 MbpsSSL VPN Throughput–66 Byte Packet forwarding rate• Upload/Download: 954.50 Mbps • Bi-Directional: 1130.00 Mbps1,518 Byte Packet forwarding rate• Upload/Download: 997.50 Mbps • Bi-Directional: 1965.00 MbpsBASIC FUNCTIONSWAN Connection Type• Static/Dynamic IP • PPPoE • PPTP • L2TP • Mobile Broadband: 4G/3G modem for backup via USB port‡MAC CloneModify WAN/LAN MAC Address†DHCP• DHCP Server/Client • DHCP Address Reservation • Multi-net DHCP* • Multi-IP Interfaces*IPv6StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThroughVLAN802.1Q VLANIPTVIGMP v2/v3 Proxy, Custom Mode, Bridge ModeADVANCED FUNCTIONSACLIP/Port/Protocol/Domain Name FilteringAdvanced Routing• Static Routing • Policy RoutingBandwidth ControlIP-based Bandwidth ControlLoad Balance• Intelligent Load Balance • Application Optimized Routing • Link Backup (Timing§, Failover) • Online DetectionNAT• One-to-One NAT§ • Multi-Net NAT • Virtual Server • Port Triggering§ • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG, UPnPSecurity• SPI Firewall • VPN Passthrough • FTP/H.323/PPTP/SIP/IPsec ALG • DoS Defence, Ping of Death • Local ManagementSession LimitIP-based Session LimitVPNIPsec VPN• 20 IPsec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, AES128, AES192, AES256 Encryption Algorithm • IKEv1/v2 • MD5, SHA1 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS)PPTP VPN• PPTP VPN Server • 10 PPTP VPN Clients** • 16 Tunnels • PPTP with MPPE EncryptionL2TP VPN• L2TP VPN Server • 10 L2TP VPN Clients** • 16 Tunnels • L2TP over IPSecOpenVPN• OpenVPN Server* • 10 OpenVPN Clients*△ • 16 OpenVPN Tunnels*AUTHENTICATIONWeb Authentication• No Authentication • Simple Password* • Hotspot（Local User / Voucher* / SMS* / Radius*） • External Radius Sever • External Portal Sever* • Facebook*MANAGEMENTOmada AppYes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.Centralized Management• Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller • Omada Cloud-Based ControllerCloud AccessYes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.ServiceDynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)Maintenance• Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3 • Diagnostics (Ping & Traceroute)§ • NTP Synchronize§ • Syslog SupportZero-Touch ProvisioningYes. Requiring the use of Omada Cloud-Based Controller.Management Features• Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal ConfigurationOTHERSCertificationCE, FCC, RoHSPackage Contents• Gigabti VPN Router ER605 • Power Adapter • RJ45 Ethernet Cable • Quick Installation GuideSystem RequirementsMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11, MAC OS, NetWare, UNIX or LinuxEnvironment• Operating Temperature: 0–40 ℃ (32–104 ℉); • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing รหัสสินค้า: TPL-ER605 หมวดหมู่: Router TP-Link
